360 Degree Tube Multivariant Style Shapes

Author:Ibestwork Technology Ltm Click: Time:2018-01-01 00:00:00


3D DMX Magic RGB LED Tube Features:

* Multivariant Style Shapes

1. 360° Lighting design, achieve any 3D effect that you want.

2. DMX Surpot standard DMX512.

3. 15V voltage supply, lower power, less heat.

4. Pixel control every 2 leds or 1 led on each side can be controlled as one pixel.

5. Programming easily via MA, AI, Madmapper, Madrix Etc.

6. Music active,mcontrol the light makes you say "WOW"!

7. Smart easy installation, variety size available (Length: 0.4M, 0.8M, 1.2M)

8. Application Clubs&bars, stage, concert, theater, and kinds of events, Etc.


ModelIBW-L-501AIBW-L-502BIBW-L-502C
Diameter50mm50mm50mm
Length400mm800mm1200mm
LEDSMD RGB 5050SMD RGB 5050SMD RGB 5050
LED QTY16x2pcs32x2pcs48x2pcs
Pixel QTY8 pixels16pixels24 pixels
Tube Qty/Universe20 pcs10 pcs7 pcs
VoltageDC15VDC15VDC15V
Power8W14.4W21.6W
DMX channel24
4872
Beam angle360360360
Control ModeDMX512DMX512DMX512
Address SettingManuallyManuallyManually
LED Source Life50,000hours,based on LED manufacturers test data
Housingmilky cover, aluminum base
Temperature-4℉ to 122℉(-20℃ to 50℃) operating temperature
Humidity Range0 to 95% non-condensing
ProtectionIP65
